Tektronix adds 5G capabilities to its award-winning, high-performance oscilloscopes

Tektronix has released its SignalVu 5G NR analysis software for 6 Series B MSO oscilloscopes. Engineers can now perform critical 5G NR measurements per 3GPP specifications on the oscilloscopes they rely on to bring-up and characterize new electronic designs.

6 Series B MSO oscilloscopes are said to be preferred by RF system designers for viewing power rails, digital control buses and I/O signals, in addition to RF signals. Each channel is backed by a digital downconverter that enables spectrum analysis synchronized with time-domain waveforms. This provides engineers with a time-coherent view of the choreography of signals that make up their designs. 5G system designers can now add 5G NR signal analysis to Tektronix oscilloscopes, which enables them to quickly diagnose faulty signal interactions on a single oscilloscope that would otherwise require painstaking correlation between multiple instruments.

In addition to the ability to give a synchronized view of a wide variety of signals, the 6 Series B MSO offers the wide capture bandwidth and low intrinsic noise needed for 5G signal analysis. Offering this performance on oscilloscopes reduces the need for costly dedicated vector signal analysers.

“With the integration of 5G NR, users have complete system visibility in a single instrument enabling them to debug even the most complex of designs, aligning with future specifications,” said Chris Witt, VP and GM of Portfolio Solutions at Tektronix.

The new analysis package enables pass/fail testing of the 5G NR physical layer to qualify transmitter designs per the 5G NR standard established under the 3GPP release of 15/16 test specifications. It includes important signal quality measurements such as Error Vector Magnitude (EVM), Adjacent Channel Power (ACP), Spectral Emission Mask (SEM), and Power Versus Time (PVT).

Tektronix developed the new 5G NR analysis package using algorithms developed by NI (formerly National Instruments), a recognised market leader in automated test and measurement.

“NI was excited to work with Tektronix to provide multiple ways to trigger, capture, analyze, and diagnose complex 5G integration and design problems not normally available with a traditional VSA,” said Josh Mueller, SVP and GM of Portfolio Business. “Integrating NI’s 5G algorithms within SignalVu vector signal analysis (VSA) software to run on the Tektronix oscilloscopes and signal analysers will enable new value in customer workflows.”

The 5G NR PHY-layer solution based on the Tektronix 6 Series B MSO offers significant advantages over traditional signal analysers with wide signal analysis up to 2 GHz and low instrument noise for accurate EVM measurements.

For high frequency systems, such as FR2, the 5GNR analysis option is also available on the DPO70000SX which offers up to 70 GHz bandwidth. For engineers using real-time signal analysers, the 5GNR option is also available for the Tektronix RSA500 and RSA5000 Series. The software operates identically on oscilloscopes and signal analysers, eliminating the need to learn a new toolset.

The SignalVu 5GNR Signal Analysis option is now available globally for 6 Series B MSO oscilloscopes, DPO70000SX oscilloscopes, and RSA500 and RSA5000 signal analyzers. Learn about Tektronix 5G Testing on our website.
