congatec – a leading vendor of embedded computing technology – presents its brand new workload consolidation kit for vision based situational awareness that is qualified by Intel as Intel IoT RFP (Ready For Production) Kit.
Based on a COM Express Type 6 module equipped with Intel Xeon E2 processor, the RFP kit has three virtual machines (VMs) built on Real-Time Systems’ hypervisor technology for workload consolidation in vision applications. One VM runs a vision based AI application on the basis of Intel OpenVino software for situational awareness, the second VM is real-time capable and runs deterministic control software, and the third VM operates a IIoT/Industry 4.0 gateway. The congatec kit designed in cooperation with Intel and Real-Time Systems targets the next generation of vision based collaborative robotics, automation controls and autonomous vehicles that have to tackle multiple tasks in parallel, including situational awareness utilising deep learning based AI algorithms.
The Real-Time Systems based virtual machines make it possible to consolidate the different tasks on a single edge computing platform, which ultimately saves costs. The Intel OpenVino software delivers the appropriate artificial intelligence for situational awareness. OEMs just need to load their control to the real-time VM and they are ready to enrich their real-time control with data from the situational awareness VM and to communicate in real-time with IIoT/Industry 4.0 counterparts to enable tactile internet controls.
“Workload consolidation demand is rapidly increasing in vision based situational awareness applications: Machine controls, collaborative robotics and autonomous vehicles need virtualisation, as OEMs don’t want to assign the different control, vision and networking tasks to multiple dedicated systems,” explains Martin Danzer, Director Product Management at congatec.
The workload consolidation RFP kit unpacked
congatec’s ‘Intel IoT RFP Kit’ for workload consolidation in vision based situational awareness applications includes a COM Express Type 6 module based platform with Intel Xeon E2 processor, a Basler vision camera, a pendulum controlled by a demo controller, and an Intel Arria 10 FPGA card from REFLEX CES. The platform has three pre-installed application ready VMs on the basis of Real-Time Systems’ hypervisor technology. One VM analyses videos on the basis of Intel OpenVino software, the second VM runs real-time Linux to control the balance of an inverted pendulum in real-time. The third partition hosts a gateway for IIoT/Industry 4.0 connectivity. More information about the new Intel IoT RFP Kit for workload consolidation is available at:
